Urbanature

Urbanature

Five warm and captivating colours for a modern look

The metropolitan evolution of style: the rediscovery of the elementary materials that make up the urban fabric.


- Made in Italy -

Product range

Colours Decors Trim Pieces

Floors and Walls porcelain tiles

Floors and Walls laminated porcelain stoneware

Technical specs

Floors and Walls porcelain tiles

Test method Required value Average values
Water absorption ASTM C373 ≤ 0.5% 0.05%
Breaking strengh ASTM C648 ≥ 250 lbf CONFORMS
Deep abrasion resistance ASTM C1243 ≤ 175 mm3 145 mm3
Linear thermal expansion ASTM C372 Not Required

α ≤ 8 x 10-6 °C-1

α ≤ 4.4 x 10-6 °F-1

Stain resistance ASTM C1378 As indicated by manufacturer A RESISTANT
Chemical resistance
Lead and cadmium given off
ASTM C650
ASTM C895
As indicated by manufacturer
NO PROVISION
A RESISTANT (Excluding hydrofluoridric acid and its derivates)
NOT APPLICABLE
Frost resistance ASTM C1026 As indicated by manufacturer RESISTANT
Slip resistance DIN 51130
BCR-TORTUS
ANSI A326.3
DIN 51097
PENDULUM AS/NZS 4586
PENDULUM BS 7976-2

-
Porcelain A326.3



R9 (NAT, LAPPATO)
> 0,40 (NAT) - (LAPPATO)
≥ 0.42 (NAT) - (LAPPATO)
- (NAT, LAPPATO)
Shade variation ANSI A137.1 As indicated by manufacturer V2 SLIGHT VARIATION
Flame spread
Fire reaction
ASTM E84
EN 9239-1 - EN 13823
- CLASS A

CLASSE A1 FL (floor installation)

CLASSE A1 (wall installation)

Thermal conductivity EN 12524 - λ = 1,3 W/m °K / 0.7 BTU/ft h °F
Thermal shock resistance ISO 10545-9 No alterations Resistant

Outdoor floors 20mm porcelain tiles

Test method Required value Average values
Water absorption ASTM C373 ≤ 0.5% 0.05%
Breaking strengh ASTM C648 ≥ 250 lbf 2800 lbf
Deep abrasion resistance ASTM C1243 ≤ 175 mm3 145 mm3
Linear thermal expansion ASTM C372 Not Required

α ≤ 8 x 10-6 °C-1

α ≤ 4.4 x 10-6 °F-1

Stain resistance ASTM C1378 As indicated by manufacturer A RESISTANT
Chemical resistance ASTM C650 As indicated by manufacturer A RESISTANT (Excluding hydrofluoridric acid and its derivates)
Frost resistance ASTM C1026 As indicated by manufacturer RESISTANT
Slip resistance DIN 51130
BCR-TORTUS
ANSI A326.3
DIN 51097
PENDULUM AS/NZS 4586
PENDULUM BS 7976-2

-
Porcelain A326.3



R11 (STRUCT, 20mm)
> 0,50 (STRUCT, 20mm)
≥ 0.62 (STRUCT, 20mm)
A+B+C (STRUCT, 20mm)
P4 (STRUCT, 20mm)
36+ (STRUCT, 20mm)
Flame spread
Fire reaction
ASTM E84
EN 9239-1
- CLASS A
CLASSE A1 FL (floor installation)
Thermal conductivity EN 12524 - λ = 1,3 W/m °K / 0.7 BTU/ft h °F
Thermal shock resistance ISO 10545-9 No alterations Resistant

Downloads

Certification EPD Porcelain stoneware 9mm PDF - 1.40 MB pdf
Declaration of Performance DOP Porcelain tile PDF - 0.29 MB pdf
Certification Recycled content 40% - Italy PDF - 0.27 MB pdf
Certification ISO 9001 Panaria - Panariagroup PDF - 2.27 MB pdf
Certification ISO 14001 Panariagroup PDF - 0.70 MB pdf
Certification EMAS Toano PDF - 0.14 MB pdf
Certification EMAS Finale Emilia PDF - 0.47 MB pdf
Certifications Declare. - Laminated Porcelain Slabs with fiberglass mesh PDF - 0.88 MB pdf
Declaration of Performance Laminated Porcelain 3Plus PDF - 0.58 MB pdf
Tender specs Urbanature PDF - 0.20 MB pdf
