Pietre di Fanes

Pietre di Fanes

Tradition meets the present: in classic and modern spaces the result is always rich in allure.

Nature all around me.


- Made in Italy -

Product range

Colours Trim Pieces

Floors and Walls porcelain tiles

Technical specs

Test method Required value Average values
Water absorption ASTM C373 ≤ 0.5% 0.05%
Breaking strengh ASTM C648 ≥ 250 lbf CONFORMS
Deep abrasion resistance ASTM C1243 ≤ 175 mm3 145 mm3
Linear thermal expansion ASTM C372 NO PROVISION

α ≤ 8 x 10-6 °C-1

α ≤ 4.4 x 10-6 °F-1

Stain resistance ASTM C1378 As indicated by manufacturer A RESISTANT
Chemical resistance
Lead and cadmium given off
ASTM C650
ASTM C895
As indicated by manufacturer
NO PROVISION
A RESISTANT (Excluding hydrofluoridric acid and its derivates)
NOT APPLICABLE
Frost resistance ASTM C1026 As indicated by manufacturer RESISTANT
Slip resistance DIN 51130
BCR-TORTUS
ANSI A326.3
DIN 51097

-

R11
> 0,50
≥ 0.42
A+B+C
Shade variation ANSI A137.1 As indicated by manufacturer V4 SUBSTANTIAL VARIATION
Flame spread
Fire reaction
ASTM E84
EN 9239-1 - EN 13823
- CLASS A
CLASSE A1 FL (floor installation) CLASSE A1 (wall installation)
Thermal conductivity EN 12524 - λ = 1,3 W/m °K / 0.7 BTU/ft h °F
Thermal shock resistance ISO 10545-9 No alterations Resistant

Downloads

Certification Recycled content 40% - Italy PDF - 0.30 MB pdf
Certification ISO 9001 Panaria - Panariagroup PDF - 0.25 MB pdf
Certification ISO 14001 Panariagroup PDF - 0.39 MB pdf
Declaration of Performance Porcelain tile PDF - 0.26 MB pdf
Certification EMAS Finale Emilia PDF - 0.47 MB pdf
Tender specs Pietre di Fanes PDF - 0.19 MB pdf
