Opificio 22/a

the strong and gentle soul of cement

A multifaceted and harmonious set of surfaces, marked by the traces of the passage of time.

Product range

Colours Decors Trim Pieces

Floors and Walls porcelain tiles

Outdoor floors 20mm porcelain tiles

Technical specs

Test method Required value Average values
Water absorption ASTM C373 ≤ 0.5% 0,05%
Breaking strenght ASTM C648 ≥ 125 lbf 290 lbf 8 mm
600 lbf 10 mm
700 lbf 11 mm
2,800 lbf 20 mm
Deep abrasion resistance ASTM C1243 ≤ 175 mm3 145 mm3
Linear thermal expansion ASTM C372 NO PROVISION

α ≤ 7 x 10-6 °C-1

α ≤ 4.4 x 10-6 °F-1/α ≤ 8 x 10-6 °C-1

Stain resistance ASTM C1378 As indicated by manufacturer A RESISTANT
Chemical resistance ASTM C650 As indicated by manufacturer A RESISTANT
Frost resistance ASTM C1026 As indicated by manufacturer RESISTANT
Slip resistance DIN 51130
BCR-TORTUS
ANSI A326.3
DIN 51097
PENDULUM AS/NZS 4586
PENDULUM BS 7976-2

-
DCOF ≥ 0.42



R10 Naturale R11 Ext, Strutturato
µ > 0,40
DCOF ≥ 0.42
A Naturale C (A+B+C) Ext, Strutturato
P4 Ext, Strutturato
PTV 36+ wet (SI. 96 - SI. 55) Ext, Strutturato
Shade variation ANSI A137.1 As indicated by manufacturer V4 Substantial variation
Flame spread ASTM E84 - CLASS A
Thermal conductivity EN 12524 - λ = 1,3 W/m °K / 0.7 BTU/ft h °F

Downloads

Opificio 22/A Tender specs pdf
